产品规格
产品指标一
| 光纤类型 | GDF_DC 34/90-0.095 | GDF_SC 10/125-0.08 | GDF_DC 10/130-0.08 | GDF_SC 20/130-0.08 | GDF_DC 20/130-0.08 | GDF_DC 14/250-0.07 | GDF_DC 25/250-0.085 | GDF_DC 25/250-0.11 | |
| 产品编号 | DG1113-G | SG1010-C | DG1110-A | SG1011-A | DG1111-A | DG1110-C | DG1112-A | DG1112-D | |
| 光学性能 | |||||||||
| 工作波长 (nm) | 1060 ~ 1110 | 900 ~ 1600 | |||||||
| 纤芯数值孔径 | 0.095 ± 0.005 | 0.08 ± 0.005 | 0.08 ± 0.005 | 0.08 ± 0.005 | 0.08 ± 0.005 | 0.070 ± 0.005 | 0.085 ± 0.005 | 0.11 ± 0.01 | |
| 包层数值孔径 | ≥ 0.46 | - | ≥ 0.46 | - | ≥ 0.46 | ≥ 0.46 | ≥ 0.46 | ≥ 0.46 | |
| 纤芯损耗 @1300nm (dB/km) | ≤ 10.0 | ≤ 40.0 | ≤ 40.0 | ≤ 40.0 | ≤ 40.0 | ≤ 45.0 | ≤ 45.0 | ≤ 45.0 | |
| 纤芯损耗 @1200nm (dB/km) | ≤ 10.0 | ≤ 20.0 | ≤ 20.0 | ≤ 20.0 | ≤ 20.0 | ≤ 20.0 | ≤ 45.0 | ≤ 30.0 | |
| 包层损耗 @1095nm (dB/km) | ≤ 10.0 | - | ≤ 15.0 | - | ≤ 15.0 | ≤ 15.0 | ≤ 15.0 | ≤ 15.0 | |
| 几何/机械特性 | |||||||||
| 芯层直径 (μm) | 25.0 ± 1.5 | 11.0 ± 1.0 | 11.0 ± 1.0 | 20.0 ± 1.5 | 20.0 ± 1.5 | 14.0 ± 1.5 | 25.0 ± 1.5 | 25.0 ± 1.5 | |
| 包层直径 (μm) | 90.0 ± 1.5 | 125.0 ± 1.0 | 130.0 ± 1.0 | 130.0 ± 2.0 | 130.0 ± 1.0 | 247.0 ± 3.0 | 247.0 ± 3.0 | 247.0 ± 3.0 | |
| 涂层直径 (μm) | 190.0 ± 15.0 | 245.0 ± 10.0 | 245.0 ± 10.0 | 245.0 ± 10.0 | 245.0 ± 10.0 | 295.0 ± 15.0 | 295.0 ± 15.0 | 295.0 ± 15.0 | |
| 芯/包同心度（μm） | ≤ 0.5 | ≤ 0.7 | ≤ 0.7 | ≤ 0.7 | ≤ 0.7 | ≤ 2.0 | ≤ 2.0 | ≤ 2.0 | |
| 包层不圆度 (%) | ≤ 0.5 | ||||||||
| 筛选张力 (kpsi) | ≥ 100 | ||||||||
产品指标二
| 光纤类型 | GDF_SC 30/250-0.065 | GDF_DC 30/250-0.065 | GDF_DC 30/250-0.075 | GDF_DC 34/250-0.075 | GDF_DC 34/250-0.11 | |
| 产品编号 | SG1011-C | DG1113-A | DG1113-E | DG1113-H | DG1113-C | |
| 光学性能 | ||||||
| 工作波长 (nm) | 1060 ~ 1110 | |||||
| 纤芯数值孔径 | 0.075 ± 0.005 | 0.065 ± 0.005 | 0.075 ± 0.005 | 0.075 ± 0.005 | 0.11 ± 0.01 | |
| 包层数值孔径 | - | ≥ 0.46 | ≥ 0.46 | ≥ 0.46 | ≥ 0.46 | |
| 纤芯损耗 @1300nm (dB/km) | ≤ 40.0 | ≤ 45.0 | ≤ 45.0 | ≤ 15.0 | ≤ 45.0 | |
| 纤芯损耗 @1200nm (dB/km) | ≤ 10.0 | ≤ 30.0 | ≤ 30.0 | ≤ 20.0 | ≤30.0 | |
| 包层损耗 @1095nm (dB/km) | - | ≤ 15.0 | ≤ 15.0 | ≤ 15.0 | ≤ 15.0 | |
| 几何/机械特性 | ||||||
| 芯层直径 (μm) | 30.0 ± 1.5 | 30.0 ± 1.5 | 30.0 ± 1.5 | 34.0 ± 1.5 | 35.0 ± 1.5 | |
| 包层直径 (μm) | 247.0 ± 3.0 | |||||
| 涂层直径 (μm) | 395.0 ± 15.0 | |||||
| 芯/包同心度（μm） | ≤ 2.0 | |||||
| 包层不圆度 (%) | ≤ 0.5 | |||||
| 筛选张力 (kpsi) | ≥ 100 | |||||
产品指标三
| 光纤类型 | GDF_DC 20/400-0.065 | GDF_DC 25/400-0.065 | GDF_DC 25/400-0.11 | GDF_DC 30/400-0.06 | GDF_DC 34/400-0.065 | GDF_DC 50/400-0.11 | GDF_DC 50/400-0.12 | |
| 产品编号 | DG1111-C | DG1112-B | DG1112-C | DG1113-B | DG1113-J | DG1115-B | DG1115-E | |
| 光学性能 | ||||||||
| 工作波长 (nm) | 1060 ~ 1110 | |||||||
| 纤芯数值孔径 | 0.065 ± 0.005 | 0.065 ± 0.005 | 0.11 ± 0.01 | 0.06 ± 0.005 | 0.06 ± 0.005 | 0.11 ± 0.01 | 0.12 ± 0.01 | |
| 包层数值孔径 | ≥ 0.46 | ≥ 0.46 | ≥ 0.46 | ≥ 0.46 | ≥ 0.46 | ≥ 0.46 | ≥ 0.46 | |
| 纤芯损耗 @1300nm (dB/km) | ≤ 20.0 | ≤ 20.0 | ≤ 12.0 | ≤ 20.0 | ≤ 15.0 | ≤ 20.0 | ≤ 40.0 | |
| 纤芯损耗 @1200nm (dB/km) | ≤ 15.0 | ≤ 15.0 | ≤ 8.0 | ≤ 15.0 | ≤ 15.0 | ≤ 15.0 | ≤ 20.0 | |
| 包层损耗 @1095nm (dB/km) | ≤ 15.0 | ≤ 15.0 | ≤ 15.0 | ≤ 15.0 | ≤ 15.0 | ≤ 15.0 | ≤ 15.0 | |
| 几何/机械特性 | ||||||||
| 芯层直径 (μm) | 20.0 ± 1.5 | 25.0 ± 1.5 | 25.0 ± 1.5 | 30.0 ± 2.0 | 34.0 ± 1.5 | 50.0 ± 1.5 | 25.0 ± 2.0 | |
| 包层直径 (μm) | 395.0 ± 5.0 | 395.0 ± 5.0 | 395.0 ± 5.0 | 400.0 ± 5.0 | 395.0 ± 5.0 | 395.0 ± 5.0 | 395.0 ± 5.0 | |
| 涂层直径 (μm) | 550.0 ± 15.0 | 550.0 ± 15.0 | 550.0 ± 15.0 | 550.0 ± 15.0 | 550.0 ± 15.0 | 550.0 ± 15.0 | 550.0 ± 15.0 | |
| 芯/包同心度（μm） | ≤ 2.0 | ≤ 2.0 | ≤ 2.0 | ≤ 2.0 | ≤ 2.0 | ≤ 2.0 | ≤ 2.0 | |
| 包层不圆度 (%) | ≤ 0.5 | ≤ 0.5 | ≤ 0.5 | ≤ 0.5 | ≤ 0.5 | ≤ 0.5 | ≤ 0.5 | |
| 筛选张力 (kpsi) | ≥ 100 | ≥ 100 | ≥ 100 | ≥ 100 | ≥ 100 | ≥ 100 | ≥ 100 | |
产品指标四
| 光纤类型 | GDF_DC 30/600-0.06 | GDF_DC 50/600-0.065 | GDF_DC 50/800-0.065 | GDF_DC 100/400-0.12 | GDF_DC 200/360-0.12 | GDF_DC 30/540-0.12 | GDF_DC 400/650-0.1 | |
| 产品编号 | DG1113-L |
DG1115-F |
DG1115-G | DG1116-B | DG1117-A | DG1117-B | DG1117-C | |
| 光学性能 | ||||||||
| 工作波长 (nm) | 1060 ~ 1110 | |||||||
| 纤芯数值孔径 | 0.06 ± 0.005 | 0.065 ± 0.005 | 0.065 ± 0.005 | 0.12 ± 0.01 | 0.12 ± 0.01 | 0.12 ± 0.01 | 0.095 ± 0.005 | |
| 包层数值孔径 | ≥ 0.46 | ≥ 0.46 | ≥ 0.46 | ≥ 0.46 | ≥ 0.46 | ≥ 0.46 | ≥ 0.46 | |
| 纤芯损耗 @1300nm (dB/km) | - | ≤ 15.0 | - | - | ≤ 40.0 | - | - | |
| 纤芯损耗 @1200nm (dB/km) | ≤ 10.0 | ≤ 15.0 | ≤ 30.0 | - | ≤ 20.0 | ≤ 20.0 | ≤ 30.0 | |
| 包层损耗 @1095nm (dB/km) | - | ≤ 20.0 | - | ≤ 25.0 | ≤ 15.0 | - | ||
| 几何/机械特性 | ||||||||
| 芯层直径 (μm) | 30.0 ± 1.5 | 50.0 ± 2.0 | 50.0 ± 2.0 | 100.0 ± 2.0 | 200.0 ± 2.0 | 300.0 ± 5.0 | 400.0 ± 3.0 | |
| 包层直径 (μm) | 600.0 ± 10.0 | 600.0 ± 7.0 | 800.0 ± 1.0 | 400.0 ± 5.0 | 360.0 ± 5.0 | 540.0 ± 10.0 | 650.0 ± 5.0 | |
| 涂层直径 (μm) | 825.0 ± 20.0 | 760.0 ± 15.0 | 970.0 ± 15.0 | 550.0 ± 15.0 | 540.0 ± 15.0 | 650.0 ± 20.0 | 800.0 ± 20.0 | |
| 芯/包同心度（μm） | ≤ 2.0 | ≤ 2.0 | ≤ 2.0 | ≤ 2.0 | ≤ 2.0 | ≤ 2.0 | ≤ 3.0 | |
| 包层不圆度 (%) | ≤ 0.5 | ≤ 0.5 | - | ≤ 0.5 | ≤ 0.5 | ≤ 1.0 | ≤ 1.0 | |
| 筛选张力 (kpsi) | ≥ 100 | ≥ 100 | ≥ 100 | ≥ 100 | ≥ 100 | ≥ 100 | ≥ 100 | |
产品指标五
| 光纤类型 | SI 105/125- 22/250（PSC） | SI 135/155- 22/320（PSC） | SI 135/155- 22/250（DC） | SI 200/220- 22/320（PSC） | SI 200/220- 22/350（DC） | SI 200/242- 22/330（PSC） | SI 200/242- 22/330（DC） | SI 600/660- 22/960（DC） | SI 800/880- 22/1050（DC） | SI 1000/1100- 22/1350（DC） | |
| 产品编号 | SI2014-N | SI2014-O | SI2110-C | SI2014-A | SI2110-D | SI2015-B | SI2111-A | SI2114-B | SI2114-C | SI2114-H | |
| 光学性能 | |||||||||||
| 工作波长 (nm) | 800 ~ 1600 | 800 ~ 2100 | |||||||||
| 纤芯数值孔径 | 0.22 ± 0.02 | ||||||||||
| 包层数值孔径 | - | - | ≥ 0.46 | - | ≥ 0.46 | - | ≥ 0.46 | ≥ 0.46 | ≥ 0.46 | ≥ 0.46 | |
| 纤芯损耗 @1300nm (dB/km) | ≤ 8.0 | ≤ 40.0 | ≤ 20.0 | - | ≤ 20.0 | - | - | - | - | - | |
| 纤芯损耗 @1200nm (dB/km) | - | ≤ 20.0 | ≤ 15.0 | - | ≤ 15.0 | - | - | - | - | - | |
| 包层损耗 @1095nm (dB/km) | - | - | ≤ 15.0 | - | ≤ 15.0 | - | ≤ 15.0 | - | - | - | |
| 几何/机械特性 | |||||||||||
| 芯层直径 (μm) | 105.0 ± 3.0 | 135.0 ± 1.5 | 135.0 ± 1.5 | 200.0 ± 4.0 | 200.0 ± 4.0 | 220.0 ± 5.0 | 220.0 ± 4.0 | 600.0 ± 8.0 | 800.0 ± 10.0 | 1000.0 ± 20.0 | |
| 包层直径 (μm) | 125.0 ± 2.0 | 155.0 ± 1.0 | 155.0 ± 1.0 | 220.0 ± 3.0 | 220.0 ± 3.0 | 242.0 ± 3.0 | 242.0 ± 3.0 | 660.0 ± 10.0 | 880.0 ± 10.0 | 1100.0 ± 22.0 | |
| 涂层直径 (μm) | 250.0 ± 10.0 | 320.0 ± 10.0 | 320.0 ± 20.0 | 320.0 ± 15.0 | 350.0 ± 20.0 | 330.0 ± 20.0 | 330.0 ± 25.0 | 960.0 ± 40.0 | 1050.0 ± 40.0 | 1350.0 ± 50.0 | |
| 芯/包同心度（μm） | ≤ 3.0 | ≤ 2.0 | ≤ 3.0 | ≤ 3.0 | ≤ 3.0 | ≤ 3.0 | ≤ 3.0 | ≤ 7.0 | ≤ 10.0 | ≤ 10.0 | |
| 包层不圆度 (%) | ≤ 2.0 | ≤ 0.5 | ≤ 0.5 | ≤ 2.0 | ≤ 0.5 | ≤ 2.0 | ≤ 0.5 | ≤ 0.5 | ≤ 0.5 | ≤ 1.0 | |
| 筛选张力 (kpsi) | ≥ 100 | ≥ 100 | ≥ 100 | ≥ 100 | ≥ 100 | ≥ 100 | ≥ 100 | ≥ 100 | ≥ 100 | ≥ 70 | |
| 内涂层材料 | 丙烯酸树脂 | 丙烯酸树脂 | 低折射率涂层 | 丙烯酸树脂 | 低折射率涂层 | 丙烯酸树脂 | 低折射率涂层 | 低折射率涂层 | 低折射率涂层 | 低折射率涂层 | |
| 外涂层材料 | 丙烯酸树脂 | 丙烯酸树脂 | 丙烯酸树脂 | 丙烯酸树脂 | 丙烯酸树脂 | 丙烯酸树脂 | 丙烯酸树脂 | 丙烯酸树脂 | 丙烯酸树脂 | 丙烯酸树脂 | |
产品指标六
| 光纤类型 | SI 50/70/360- 22/540（DC） | SI 70/90/360- 22/540（DC） | SI 100/120/360- 15/540（DC） | SI 100/120/360- 22/540（DC） | SI 150/170/360- 15/540（DC） | SI 150/170/360- 22/540（DC） | SI 200/220/360- 22/540（DC） | SI 300/330/360- 22/540（DC） | |
| 产品编号 |
SI2113-A |
SI2113-B | SI2113-F | SI2113-C | SI2113-G | SI2113-D | SI2113-E | SI2113-L | |
| 光学性能 | |||||||||
| 工作波长 (nm) | 800 ~ 1600 | ||||||||
| 纤芯数值孔径 | 0.22 ± 0.01 | 0.22 ± 0.01 | 0.15 ± 0.01 | 0.22 ± 0.01 | 0.15± 0.01 | 0.22 ± 0.01 | 0.22 ± 0.01 | 0.22 ± 0.02 | |
| 包层数值孔径 | ≥ 0.46 | ≥ 0.46 | ≥ 0.46 | ≥ 0.46 | ≥ 0.46 | ≥ 0.46 | ≥ 0.46 | ≥ 0.46 | |
| 几何/机械特性 | |||||||||
| 芯层直径 (μm) | 52.0 ± 2.0 | 72.0 ± 2.0 | 102.0 ± 2.0 | 102.0 ± 2.0 | 152.0 ± 2.0 | 152.0 ± 2.0 | 204.0 ± 4.0 | 306.0 ± 5.0 | |
| 芯/包同心度（μm） | ≤ 2.0 | ≤ 2.0 | ≤ 2.0 | ≤ 2.0 | ≤ 2.0 | ≤ 2.0 | ≤ 2.0 | ≤ 5.0 | |
| 包层不圆度 (%) | ≤ 2.0 | ≤ 2.0 | ≤ 2.0 | ≤ 2.0 | ≤ 2.0 | ≤ 2.0 | ≤ 2.0 | ≤ 2.0 | |
| 筛选张力 (kpsi) | ≥ 100 | ≥ 100 | ≥ 100 | ≥ 100 | ≥ 100 | ≥ 100 | ≥ 100 | ≥ 100 | |
| 包层直径 (μm) | 73.0 ± 3.0 | 93.0 ± 3.0 | 123.0 ± 3.0 | 123.0 ± 3.5 | 173.0 ± 3.0 | 173.0 ± 3.0 | 226.0 ± 6.0 | 336.6 ± 7.0 | |
| 涂层直径 (μm) | 367.5 ± 7.5 | 367.5 ± 7.5 | 367.5 ± 5.0 | 367.5 ± 7.5 | 367.5 ± 7.5 | 367.5 ± 7.5 | 367.5 ± 7.5 | 367.5 ± 7.5 | |
| 内涂层材料 | 低折射率涂层 | ||||||||
| 外涂层材料 | 丙烯酸树脂 | ||||||||
